SUS316 cnc medical device prototype parts machining/cnc metal part

Metal Material

Aluminum, Zinc, Steel, Copper, Brass, Magnesium, Magnesium alloy, Stainless steel, Sheet metal, Bronze, Aircraft Alloys - Steel, Nickel/Super Alloys, Carbon Steel, Hi-Temperature Alloys, Medical Alloys, Glass Sealing Alloy

Engineering Plastic

PEEK, PVDF, CPVC, UPE, POM-ESD, PPS, PEI, PSU, PES, PPO, PTFE, PETP, PBT, PET, POM, PC, PAPAI, PBI, PI, PVC, ABS, PP, PE, PU, PA

Anti-static Material

PEEK, POM, PC, PVC, ABS, Silicon sheet, Nylon board, Organic glass,

Insulating Material

Bakelite, Silicon, Epoxy, Resin, Cold impact

PA+GF Material

PEEK, PPS, PEI, PETP, PBT, PET, POM, Nylon

Part Name :

 Profiling Customized shockproof galaxy note 3 case Aluminum vowin.cn/en/News/news1251.html' target='_blank'>machining

General Capabilities :

CNC Milling /     CNC Turning / Sinker EDM Machining

Industry Focus :

Aerospace                     Agricultural
Architectural                  Auto/Truck/Transportation
Dental                           Electronic
Food Processing           Marine
Medical                         Military
Natural gas                  Packaging/Converting

Tolerances:

Straightness : ± 0005/ft
Concentricity: ± .0001
Diameter (outer/inner): ± .0002 in
Length : ± .0005 in

Part Diameter :

Min: ½ in 12.7 mm
Max: 10 in 254 mm

Part Length:

Min: 1 in 25.4 mm
Max: 40 in 1016 mm

Part Width :

Min: .10 in 2.54 mm
Max: 41 in 1041.4 mm

Part Height :

Min: .10 in 2.54 mm
Max: 35 in  889 mm

Maximum Part Weight/Maximum Lifting Capacity :

Max   12 Tons

Machining Processes :

Gear Hobbing, Parting/Cutting, Facing
Turning: Contour Turning, Form Turning, Taper Turning, Straight Turning
Threading: External, Internal
Internal Forming, Knurling, Boring, Drilling, Counterboring
Countersinking, Pocketing, Profiling, Reaming, Tapping, Thread Milling

Equipment :

Lathe / Engine / Turret /  CNC( Tracer)

Fixturing :

Three-jaw chuck   / Four-jaw chuck   /In-House Fixtures & Tooling

Equipment Capabilities :

CNC Control Capabilities        CAD Design Services
CAM Programming                 Reverse Engineering

Machinery Axis :

3, 4, 5

Secondary Services Offered:

Light Assembly    Custom Packaging   Painting
Powder Coating    Welding            Plating
Heat Treating     Grinding           Anodizing

Production Volume :

Prototype ,      Low Volume ,    Mid Volume ,     Short Run , Long Run

File Formats :

• Autodesk Inventor, SolidWorks, CATIA V5, Solid Edge, UGS NX, Pro/ENGINEER
• STEP, IGES, SAT, DWG, DXF, VDA.
